M80-6814442P

Overview

The Harwin M80-6814442P is a Datamate L-Tek series socket assembly featuring 44 positions in a dual in-line configuration. It utilizes a 2 mm pitch with two rows and a 2 mm row spacing. The connector employs straight through-hole solder termination with tin-plated brass contacts rated for 3 A current and 360 V voltage. The black polyamide housing incorporates a latched locking mechanism.

Feature Summary

• Datamate L-Tek series design with integrated mechanical latching for secure mating
• Dual in-line female socket configuration with tin-plated brass contacts
• Polyamide housing material providing UL 94 V-0 flammability rating

Applications

• Industrial control system interconnections
• Test and measurement equipment signal routing
• Automotive electronics harness connections

Procurement Notes

Verify the specific suffix 'P' against the official Harwin datasheet to confirm if it denotes a distinct packaging variant or environmental certification compared to the base M80-6814442 model. Ensure compatibility with mating male headers from the same Datamate L-Tek family before finalizing procurement orders.

Selection Notes

Select this component for applications requiring high-density 44-position connections with robust mechanical retention. The 2 mm pitch allows for compact board layouts while maintaining reliable electrical performance. Verify that the straight through-hole mounting style aligns with the target PCB assembly process requirements.

Part Context

This part belongs to the Harwin Datamate L-Tek family, designed for high-reliability interconnect solutions. The series is characterized by its modular design, allowing for various contact counts and termination styles. The M80 prefix indicates the standard Datamate form factor within the broader connector portfolio.

Replacement Considerations

M80-6814442
