M80-7003605

Overview

The M80-7003605 is a male connector from the Datamate Mix-Tek series, manufactured by Harwin Inc. It features a 3-row configuration with a 2mm pitch and 36 positions. Designed for through-board PCB tail termination, it utilizes crimp contacts with gold plating. The housing is constructed from black polyphenylene sulfide (PPS). Key specifications include a rated current of 3A, voltage rating of 120V, and an operating temperature range of -55°C to +125°C.

Feature Summary

• Three-row male connector design for high-density applications
• Through-board PCB tail termination method
• Gold-plated crimp contacts for reliable signal transmission
• Polyphenylene sulfide housing material for thermal stability

Applications

• Industrial control systems requiring robust interconnects
• Automotive electronics harnesses
• Military and aerospace equipment
• General purpose power distribution boards

Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to ensure correct contact type and termination style. Confirm that the required crimping tool, such as the M22520 series, is available for proper assembly. Check for RoHS compliance status if environmental regulations apply to your project. Ensure the selected variant matches the intended board thickness and mounting requirements.

Selection Notes

Select this component when a high-density, three-row male connector is required for through-board installation. Consider the 2mm pitch and 36-position count for space-constrained designs. Evaluate the 3A current rating and 120V voltage limit against circuit demands. Ensure compatibility with existing Datamate Mix-Tek mating sockets and appropriate crimping tools for manufacturing.

Part Context

This part belongs to the Datamate Mix-Tek family, known for high-reliability interconnect solutions. The M80 series specifically targets demanding environments including automotive, military, and industrial sectors. It offers a balance of compact size and robust mechanical performance, utilizing PPS insulation for superior heat resistance compared to standard thermoplastics.

Replacement Considerations

Direct substitutes within the same series may include variations in row count or position number. Verify pinout compatibility before replacing. Cross-series replacements require careful evaluation of pitch, housing dimensions, and mating interface geometry to ensure mechanical and electrical fit.
