M80-7003622

Overview

The Harwin M80-7003622 is a Datamate J-Tek series male header connector designed for power-to-board applications. It features a 3-row configuration with 2mm pitch and 18 total positions (9+9). The component utilizes phosphor bronze contacts with gold plating, rated for 2.2A current and 120V voltage. It employs a through-hole solder tail termination style with a straight mounting orientation. The housing is constructed from black polyamide material, ensuring compliance with UL94 V-0 flammability standards.

Feature Summary

• High-reliability Datamate J-Tek interconnect system
• Gold-plated phosphor bronze contacts for corrosion resistance
• Straight through-hole solder tail termination
• Polyamide housing with UL94 V-0 rating

Applications

• Industrial control systems
• Automotive electronics
• Military and aerospace equipment

Procurement Notes

Verify the specific contact finish thickness and insulation material against the latest manufacturer datasheet before integration. Confirm that the 2.2A current rating aligns with the thermal management requirements of the target circuit design to ensure long-term operational stability.

Selection Notes

Select this part for applications requiring robust 3-row connectivity with a 2mm pitch. Ensure the mating connector belongs to the compatible Datamate J-Tek female series. Validate that the through-hole solder tail geometry fits the printed circuit board layout constraints.

Part Context

This component belongs to the Harwin Datamate family, known for high-density interconnect solutions. The M80-7003622 specifically serves as a male header within the J-Tek sub-series, offering reliable electrical connections in demanding environments where vibration resistance and durability are critical performance factors.

Replacement Considerations

Compatible mating connectors include Harwin M80-500 series female housings. Verify pin count and row alignment when sourcing substitutes to maintain mechanical and electrical interface integrity.
