Product Detailed Parameters
- Description：CONN RCPT 12POS 0.079 GOLD PCB
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：12
- Number of Positions Loaded：All
- Pitch - Mating：0.079" (2.00mm)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：12.0µin (0.30µm)
- Insulation Color：Black
- Insulation Height：0.202" (5.14mm)
- Contact Length - Post：0.177" (4.50mm)
- Operating Temperature：-55°C ~ 125°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：7.23mm, 7.85mm
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：-
- Voltage Rating：120V
Download product information
Overview
The M80-7701242 is a Datamate J-Tek PCB receptacle manufactured by Harwin Inc. It features a vertical through-hole mounting style with a 2 mm pitch and two rows of contacts, totaling 12 positions. The connector utilizes four-finger beryllium copper contact technology to ensure connection integrity without signal loss. It is designed for board-to-board or wire-to-board applications, offering high reliability in demanding environments.
Feature Summary
- Utilizes high-reliability four-finger beryllium copper contact technology
- Ensures connection integrity without loss of signal
- Vertical PC tail socket assembly design
Applications
- Board-to-board interconnections
- Wire-to-board connections
- High-reliability electronic assemblies
Procurement Notes
Verify the specific datasheet version and RoHS compliance status directly with Harwin Inc. or authorized distributors before procurement. Confirm that the vertical PC tail configuration matches the target PCB footprint requirements. Ensure compatibility with mating male headers within the Datamate J-Tek series to guarantee proper mechanical locking and electrical performance.
Selection Notes
Select this component when a vertical, through-hole female receptacle is required for 2 mm pitch systems. The four-finger contact design offers superior retention and conductivity compared to standard contacts. Consider the 12-position count and dual-row layout for space-constrained designs needing robust signal transmission.
Part Context
This part belongs to the Datamate J-Tek series, known for its compact size and high density. The M80-7701242 specifically serves as a socket assembly, providing a reliable interface for mating pins. Its construction supports industrial and commercial applications requiring durable, repeatable connections.
Replacement Considerations
- M80-7701242
FAQ
What material is used for the contacts in the M80-7701242?
The contacts are made from beryllium copper, utilizing Harwin's four-finger technology.
Is this connector suitable for board-to-board applications?
Yes, it is designed for both board-to-board and wire-to-board interconnections.
