M80-7712622

Overview

The M80-7712622 is a rectangular connector header from the Datamate L-Tek series manufactured by Harwin Inc. It features 26 positions arranged in a dual-row configuration with a 0.079-inch (2.00mm) pitch. The connector utilizes male pin contacts with gold plating and is designed for board-to-board or cable interconnect applications. It supports through-hole mounting and operates within a temperature range of -55°C to 125°C.

Feature Summary

• Dual-row header design for compact high-density interconnects
• Gold-plated male pins ensure reliable signal transmission
• Compatible with standard 2.00mm pitch mating systems

Applications

• Aviation electronic systems
• Defense equipment interfaces
• Industrial control modules
• Medical instrumentation boards

Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm exact contact plating thickness and insulation material properties. Ensure compatibility with mating receptacles from the same Datamate L-Tek family. Confirm that the through-hole termination method aligns with your PCB assembly capabilities and thermal profile requirements.

Selection Notes

Select this component when a robust, dual-row header is required for harsh environments. The Datamate L-Tek series offers high reliability and secure locking mechanisms. Consider the 26-position count and 2.00mm spacing to ensure it fits within the designated board area while maintaining adequate clearance for adjacent components.

Part Context

This part belongs to the Datamate L-Tek series, known for high-reliability interconnect solutions. It is distinct from the Mix-Tek or J-Tek variants which may feature different contact types or locking styles. The M80-7712622 specifically addresses needs for durable male headers in space-constrained, high-vibration applications common in aerospace and defense sectors.

Replacement Considerations

M80-7712642
