M80-7902201

$4.90

Description：DATAMATE L-TEK SIL FEMALE VERTIC
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:5da8dff3ef56 Category: Headers, Receptacles, Female Sockets Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：DATAMATE L-TEK SIL FEMALE VERTIC
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board or Cable
Number of Positions：22
Number of Positions Loaded：All
Pitch - Mating：0.079" (2.00mm)
Number of Rows：1
Row Spacing - Mating：-
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Locking Ramp
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：12.0µin (0.30µm)
Insulation Color：Black
Insulation Height：0.202" (5.14mm)
Contact Length - Post：0.177" (4.50mm)
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Tin-Lead
Mated Stacking Heights：7.23mm, 7.83mm
Ingress Protection：-
Features：-
Current Rating (Amps)：-
Voltage Rating：120V

Download product information

M80-7902201

Overview

The M80-7902201 is a Datamate L-Tek series female connector assembly manufactured by Harwin Inc. It features a vertical printed circuit board tail termination style with 22 positions arranged in a single row. The component utilizes a 2.00 mm (0.079 inch) pitch and is designed for through-hole mounting. The contacts are gold-plated, while the shell incorporates tin/lead plating. This specific part number identifies a SIL (Single In Line) female assembly intended for direct PCB integration.

Feature Summary

Vertical PC tail configuration for direct board mounting
Gold-plated contact surfaces for reliable signal transmission
Single in-line layout simplifying routing requirements

Applications

Industrial control panel interconnections
Test and measurement equipment signal paths
Embedded system data acquisition modules

Procurement Notes

Verify that the application requires a vertical PC tail orientation rather than a crimp or surface mount variant. Confirm the 22-position count matches the design schematic exactly. Ensure the tin/lead shell specification aligns with environmental compliance requirements if lead-free materials are mandated for the final product assembly.

Selection Notes

Select this model when a low-profile vertical connection is necessary to minimize board space usage. The Datamate L-Tek series offers robust mechanical retention suitable for high-vibration environments. Consider mating headers from the same series to ensure proper alignment and locking mechanism compatibility within the connector ecosystem.

Part Context

This component belongs to the Datamate L-Tek family, which provides compact rectangular connectors for dense wiring applications. The L-Tek series distinguishes itself with a pin-locking mechanism for secure engagement. As a female assembly, it serves as the receptacle counterpart to male pin headers, facilitating modular system expansion and serviceability.
