M80-8260642

Overview

The M80-8260642 is a surface-mount PCB header from the Harwin Datamate L-Tek series. It features a 2-row, 6-position configuration with a 2mm pitch. The connector utilizes gold-plated phosphor bronze contacts and a PPS housing. Rated for 120V and 3A, it operates within a temperature range of -55°C to 105°C.

Feature Summary

• Datamate L-Tek series design for board-to-board and wire-to-board connectivity
• Surface-mount termination for automated assembly integration
• Gold-plated phosphor bronze contacts ensuring reliable signal transmission

Applications

• Industrial control systems requiring robust interconnects
• Medical equipment needing high-reliability signal paths
• Automotive electronics utilizing surface-mount technologies

Procurement Notes

Verify the specific datasheet version against the manufacturer's official documentation to confirm current ratings and material specifications. Ensure compatibility with mating connectors in the Datamate L-Tek family. Cross-reference pin counts and row configurations to prevent installation errors during procurement.

Selection Notes

Select this component for applications requiring a compact, dual-row header with surface-mount capabilities. Consider the 2mm pitch and 3A current rating when designing circuit layouts. Verify that the operating temperature range meets the environmental requirements of the target application before finalizing the selection.

Part Context

This part belongs to the Datamate L-Tek series, designed for high-density interconnections. It serves as a male header counterpart to female sockets within the same ecosystem. The series emphasizes reliability and ease of use in space-constrained electronic designs.

Replacement Considerations

M80-8260642 is a specific variant within the Datamate L-Tek line. Direct substitutes must match the 2x3 pin count, 2mm pitch, SMD orientation, and L-Tek locking mechanism. Generic headers may lack the specific mechanical retention features.
