M80-8370345

Overview

The M80-8370345 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a single row of three male pins with a 2.00mm pitch. Designed for through-hole right-angle mounting, it utilizes phosphor bronze contacts with gold plating and a black PPS housing rated UL94 V-0. The component supports a maximum current of 2.2A at 120V, operating within a temperature range of -55°C to +125°C.

Feature Summary

• Right-angle through-hole mounting configuration
• Gold-plated phosphor bronze contacts
• High-temperature resistant PPS insulation

Applications

• Industrial control systems
• Medical equipment
• Metering devices

Procurement Notes

Verify the specific suffix against official datasheets to confirm pin count and orientation. Ensure compatibility with mating sockets in the same series. Check RoHS compliance status prior to integration into regulated assemblies.

Selection Notes

Select this part for compact vertical board-to-board connections requiring reliable signal transmission. The right-angle design optimizes space efficiency. Confirm that the 2.00mm pitch matches the target PCB layout and mating interface requirements.

Part Context

This component belongs to the Datamate L-Tek family, known for rugged interconnect solutions. It serves as a standard header variant within Harwin's portfolio, providing secure mechanical locking and electrical continuity for demanding environments.

Replacement Considerations

Consult official cross-reference lists for direct substitutes. Verify identical pitch, contact type, and mounting style before considering alternatives.
