Product Detailed Parameters
- Description：CONN HEADER R/A 6POS 2MM
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Plug
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：6
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Friction Lock
- Contact Length - Mating：-
- Contact Length - Post：0.118" (3.00mm)
- Overall Contact Length：-
- Insulation Height：0.235" (5.97mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Tin
- Contact Material：Phosphor Bronze
- Insulation Material：Polyamide (PA46), Nylon 4/6
- Features：Strain Relief Clips
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：120V
Download product information
Overview
The M80-8390642 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a 6-position (3+3) dual in-line configuration with a 2mm pitch. Designed for right-angle through-hole mounting, it utilizes male pin contacts made of phosphor bronze with tin plating. The housing is constructed from black PPS material reinforced with glass fiber, rated UL94 V-0. Electrical ratings include 120V and 3A per contact. The assembly incorporates a friction latch mechanism for secure mating.
Feature Summary
- Dual in-line structure with friction latch for secure connection
- Right-angle through-hole termination for PCB integration
- Glass-fiber reinforced PPS insulation for thermal stability
Applications
- Board-to-board interconnections
- Wire-to-board connections
- Industrial control systems requiring robust mechanical retention
Procurement Notes
Verify component obsolescence status before procurement as the part may be discontinued. Confirm that the tin-plated contacts meet environmental compliance requirements for the target application. Ensure the right-angle form factor aligns with the mechanical layout constraints of the printed circuit board design to avoid clearance issues.
Selection Notes
Select this model when a low-profile, right-angle through-hole solution with positive locking is required. The 2mm pitch allows for dense routing compared to standard 2.54mm headers. Consider the 3A current rating and 120V voltage limit to ensure electrical safety margins are maintained under operational loads.
Part Context
This component belongs to the Datamate L-Tek series, known for its compact size and high reliability. The M80-8390642 specifically addresses applications needing a 6-pin interface with enhanced mechanical security via its friction latch system, distinguishing it from standard non-latched variants within the broader connector portfolio.
Replacement Considerations
M80-8392642 is a documented substitute offering identical specifications including 26 positions, DIL configuration, right-angle male friction latch, and tin plating.
