M80-8400645

Overview

The M80-8400645 is a 6-position female socket header from the Harwin Datamate L-Tek series. It features a 2.00mm (0.079 inch) pitch and is designed for through-hole straight mounting on printed circuit boards. The connector utilizes phosphor bronze contacts with gold plating to ensure reliable signal transmission. It supports a voltage rating of up to 800V and operates within a temperature range of -55°C to +125°C, making it suitable for high-reliability applications requiring robust electrical connections.

Feature Summary

• High-voltage capability rated at 800V for demanding electrical environments
• Gold-plated phosphor bronze contacts ensure durable and low-resistance connections
• Datamate L-Tek design provides secure mating with four-finger contact technology

Applications

• Industrial control systems requiring high-voltage isolation
• Automotive electronics and power distribution modules
• Test and measurement equipment interfaces
• Medical device internal wiring connections

Procurement Notes

Verify the specific pin count and housing configuration against the official datasheet before ordering. Confirm that the through-hole footprint matches the target PCB layout. Ensure compatibility with mating male connectors from the same Datamate L-Tek series to maintain mechanical integrity and electrical performance standards.

Selection Notes

Select this component when high-voltage insulation (800V) and compact 2.00mm spacing are required. The L-Tek series offers superior retention force compared to standard variants. Consider the operating temperature range of -55°C to +125°C for environmental suitability. Ensure the application does not exceed the current carrying capacity specified in the technical documentation.

Part Context

This part belongs to the Datamate L-Tek family, known for its high reliability and resistance to vibration. The M80 series is widely used in aerospace and defense sectors due to its robust construction. The L-Tek variant specifically enhances contact retention and durability, distinguishing it from other Harwin connector lines.

Replacement Considerations

Direct substitutes must match the 6-position, 2.00mm pitch, and female socket configuration. Verify that any alternative component maintains the 800V rating and through-hole mounting style. Cross-reference mating parts to ensure mechanical compatibility with existing male headers.
