M80-8412645

Overview

The M80-8412645 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a 12-position, double in-line (DIL) configuration with two rows of six contacts each. The connector utilizes a 2.00mm pitch and employs male round pin contacts made of phosphor bronze with gold plating. Designed for through-hole mounting at a right angle, it includes an integrated four-wall shielded cover for enhanced protection. The housing is constructed from black PPS material reinforced with glass fiber, rated UL94 V-0. Electrical ratings include 120V and 3A current capacity, operating within a temperature range of -55°C to +125°C.

Feature Summary

• Integrates a four-wall shielded cover for electromagnetic interference protection
• Utilizes phosphor bronze contacts with gold plating for reliable signal transmission
• Features a rigid polyphenylene sulfide housing reinforced with glass fiber

Applications

• Board-to-board interconnections requiring shielding
• Wire-to-board connections in industrial environments
• High-density electronic assemblies needing robust mechanical retention

Procurement Notes

Verify the specific ordering suffix to confirm the inclusion of the shielded cover and the exact contact termination style. Ensure compatibility with mating female sockets from the same Datamate L-Tek series. Confirm that the through-hole footprint matches the target PCB design specifications before finalizing procurement orders.

Selection Notes

Select this component when a shielded, high-reliability connection is required for space-constrained applications. The right-angle through-hole design facilitates dense board stacking. Consider the 2.00mm pitch constraints and the 3A current rating against the system's electrical load requirements during the selection process.

Part Context

This part belongs to the Datamate L-Tek family, known for its compact size and high reliability. It is designed for demanding applications where standard connectors may fail due to vibration or EMI. The series offers various configurations including crimp and solder tail options, but this specific model is optimized for rigid PCB mounting.

Replacement Considerations

Direct substitutes must maintain the 2.00mm DIL pitch, 12-position count, and shielded cover requirement. Verify that any alternative maintains the same UL94 V-0 rating and operating temperature range to ensure environmental compatibility.
