M80-8420245

Overview

The M80-8420245 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a 2-position, single-row configuration with a 2.00mm pitch. Designed for through-hole mounting at a right angle, it utilizes male pin contacts made of phosphor bronze with gold plating on the mating surface. The housing is constructed from black polyphenylene sulfide (PPS) reinforced with glass fiber, rated UL94 V-0. Electrical ratings include 120V and 2.2A, operating within a temperature range of -55°C to 125°C.

Feature Summary

• Datamate L-Tek series design provides high reliability in harsh environments with resistance to vibration and shock.
• Four-finger contact structure ensures secure connection integrity during mating cycles.
• Includes an integrated latch mechanism for positive locking engagement with the corresponding socket.

Applications

• Industrial control systems requiring robust board-to-board connections
• Automotive electronics subject to high vibration and thermal stress
• Medical equipment demanding reliable signal transmission

Procurement Notes

Verify the specific ordering suffix against the official Harwin datasheet to ensure correct contact length and insulation height specifications. Confirm that the required latching style matches the application's mechanical constraints. Cross-reference the manufacturer part number with authorized distributors to validate authenticity and current production status before finalizing procurement orders.

Selection Notes

Select this component when a low-profile, right-angle header is needed for space-constrained designs. Ensure the mating socket belongs to the same Datamate L-Tek family to guarantee proper alignment and electrical compatibility. Consider the through-hole mounting requirement and verify PCB clearance for the angled profile during layout planning.

Part Context

This part belongs to the Datamate L-Tek family, which is engineered for applications requiring high durability and repeated mating cycles. The series is characterized by its compact 2mm pitch and robust construction, making it suitable for dense interconnect solutions where reliability under mechanical stress is critical.

Replacement Considerations

Compatible substitutes include other Harwin Datamate L-Tek headers with identical 2-position, right-angle, through-hole configurations. Verify that any alternative maintains the same 2.00mm pitch and latching mechanism to ensure mechanical interchangeability without redesigning the host PCB or mating interface.
