Product Detailed Parameters
- Description：CONN HEADER R/A 3POS 2MM
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：3
- Number of Rows：1
- Row Spacing - Mating：-
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole, Right Angle
- Termination：Solder
- Fastening Type：Latch Holder
- Contact Length - Mating：-
- Contact Length - Post：0.118" (3.00mm)
- Overall Contact Length：-
- Insulation Height：0.156" (3.96mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Gold
- Contact Material：Phosphor Bronze
- Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
- Features：Strain Relief Clips
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：120V
Download product information
Overview
The M80-8430345 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a right-angle through-hole mounting style with five male pin contacts arranged in a single row. The connector utilizes a 2.00mm pitch and incorporates strain relief clips for cable security. Electrical ratings include a current capacity of 2.2A and a voltage rating of 120V. The operating temperature range spans from -55°C to +125°C, supported by UL94 V-0 rated black PPS insulation.
Feature Summary
- Strain relief clips integrated into the housing design
- Right-angle board-to-board or cable connection capability
- High-temperature resistant Polyphenylene Sulfide (PPS) insulation
Applications
- Industrial control systems requiring secure cable connections
- Automotive electronics interfaces
- General purpose PCB interconnects
Procurement Notes
Verify the specific contact plating thickness and material composition against the official datasheet before integration. Confirm that the right-angle orientation matches the mechanical layout constraints. Ensure mating connectors are selected from the compatible Datamate L-Tek series to guarantee proper engagement and electrical continuity.
Selection Notes
Select this component when a low-profile, right-angle male header is required for 2.00mm pitch applications. The 2.2A current rating suits moderate power signals. Consider the strain relief feature if vibration resistance is critical. Verify compatibility with mating sockets regarding latch mechanisms and flange requirements.
Part Context
This part belongs to the Datamate L-Tek family, designed for high-reliability interconnect solutions. The series offers various configurations including shrouded headers and wire housings. The M80-8430345 specifically addresses needs for angled mounting in space-constrained environments while maintaining robust mechanical locking.
Replacement Considerations
Compatible substitutes within the Datamate L-Tek series include M80-8430342 and M80-8430345 variants differing only in packaging or minor suffix specifications. Ensure any replacement maintains the same 5-position count and right-angle geometry.
