M80-8430642

Overview

The Harwin M80-8430642 is a Datamate L-Tek series header connector designed for through-hole, right-angle mounting. It features five male pin contacts with a 2.00mm pitch and a single row configuration. The housing is constructed from black, glass-filled polyphenylene sulfide (PPS) rated UL94 V-0. Contacts are made of phosphor bronze, featuring selective gold plating on the mating interface and tin plating on the posts. It supports a maximum current of 2.2A at 120V, operating within a temperature range of -55°C to 125°C.

Feature Summary

• Incorporates an integrated strain relief clamp for cable stability
• Features four-wall shielding for enhanced environmental protection
• Utilizes latching base retention for secure mechanical engagement

Applications

• Industrial control systems requiring robust board-to-cable connections
• Automotive electronics applications demanding high vibration resistance
• General purpose equipment needing reliable signal transmission

Procurement Notes

Verify that the specific part number matches the required right-angle orientation and five-position count. Confirm compatibility with the corresponding Datamate L-Tek mating receptacles. Ensure the selected variant includes the necessary strain relief features for the intended cabling environment. Cross-reference official datasheets to validate material specifications against project requirements.

Selection Notes

Select this component when a rigid, right-angle connection is required for space-constrained designs. The 2.00mm pitch allows for dense circuit layouts while maintaining adequate spacing. Consider the thermal rating and current capacity to ensure compliance with system power distribution needs. Evaluate the shielding requirements to determine if the four-wall design offers sufficient protection for the application.

Part Context

This connector belongs to the Datamate L-Tek family, known for its durability in harsh environments. The M80-843 series specifically addresses applications requiring right-angle termination. It complements the broader Datamate ecosystem, providing standardized interfaces for various industrial and commercial interconnect solutions.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Verify compatibility with existing mating components before considering alternative sources.
