M80-8430742

Overview

The Harwin M80-8430742 is a Datamate L-Tek series header connector designed for power-to-board applications. It features a 7-position, single-row configuration with a 2.00mm pitch. The component utilizes male pin contacts with tin plating and is intended for through-hole mounting in a right-angle orientation. Key specifications include a rated current of 3A and an operating temperature range from -55°C to +125°C. The housing is constructed from black polyamide material, providing UL94 V-0 flammability rating. This connector supports latch mechanisms for secure mating.

Feature Summary

• Right-angle through-hole mounting for compact board integration
• Latch mechanism ensures secure connection retention
• Tin-plated male contacts for reliable conductivity
• Polyamide housing with high thermal stability

Applications

• Power distribution modules
• Industrial control systems
• Embedded electronics assemblies

Procurement Notes

Verify the specific latching variant against project requirements, as the Datamate L-Tek family includes both latched and unlatched configurations. Confirm that the tin-plated contact finish aligns with soldering or mating interface specifications. Ensure the right-angle form factor fits within the mechanical envelope constraints of the target assembly.

Selection Notes

Select this model when a right-angle, latched header is required for power delivery in space-constrained designs. The 2.00mm pitch allows for dense routing while maintaining adequate spacing. Consider the 3A current rating for load capacity and verify compatibility with corresponding socket connectors in the same series.

Part Context

This component belongs to the Harwin Datamate L-Tek Power to the Board family, which focuses on robust interconnect solutions for demanding environments. The series offers various row counts and mounting styles, with this specific part providing a 7-position option optimized for angled PCB connections.

Replacement Considerations

Compatible counterparts include other 7-position Datamate L-Tek headers with matching pitch and mounting style. Verify that substitute parts maintain the same latching mechanism and right-angle orientation to ensure mechanical interchangeability.
