M80-8500442

Overview

The M80-8500442 is a Datamate L-Tek PCB receptacle featuring a 2+2 position configuration with a 2.00 mm pitch. It utilizes female socket contacts with gold plating for reliable signal transmission. Designed for board-to-board or cable applications, it employs vertical through-hole solder termination. The housing is constructed from black Polyphenylene Sulfide (PPS) material, rated UL94 V-0 for flammability. It operates within a temperature range of -55°C to +125°C and supports up to 800V AC/DC.

Feature Summary

• High-reliability four-finger beryllium copper contacts ensure connection integrity in harsh environments.
• Vertical through-hole mounting facilitates direct PCB integration.
• Gold-plated female sockets provide durable conductive pathways.

Applications

• Board-to-board interconnections
• Wire-to-board connections
• Industrial control systems

Procurement Notes

Verify the specific contact count and row configuration against project requirements. Confirm that the vertical orientation and through-hole soldering method align with the assembly process. Ensure the operating voltage does not exceed the rated limit. Check compatibility with mating male pins regarding pitch and locking mechanisms.

Selection Notes

Select this component when a compact, high-density connector is required for vertical mounting. It is suitable for applications demanding robust mechanical stability and resistance to vibration. Consider the 2mm pitch and dual-row layout for space-constrained designs requiring multiple signal paths.

Part Context

This part belongs to the Harwin Datamate L-Tek series, designed for high-reliability applications involving shock, vibration, and acceleration. The series features durable beryllium copper contacts with a four-finger design to maintain connection integrity under stress. It is widely used in industrial and automotive sectors where environmental resilience is critical.

Replacement Considerations

No public confirmed substitute part numbers are available.
