Product Detailed Parameters
- Description：CONN RCPT 10POS 0.079 GOLD PCB
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：10
- Number of Positions Loaded：All
- Pitch - Mating：0.079" (2.00mm)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：12.0µin (0.30µm)
- Insulation Color：Black
- Insulation Height：0.202" (5.14mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-55°C ~ 125°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Tin
- Mated Stacking Heights：7.23mm, 7.85mm
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：-
- Voltage Rating：800V
Download product information
Overview
The Harwin M80-8501042 is a 10-position female receptacle connector from the Datamate J-Tek series. It features a 2-row, 2mm pitch configuration with vertical through-hole solder termination. The housing is black polyphenylene sulfide (PPS) rated UL94 V-0. Contacts are beryllium copper with gold plating on the mating surface and tin on the post. Rated for 800V and operating between -55°C and 125°C.
Feature Summary
- High-reliability four-finger beryllium copper contacts ensure connection integrity under vibration and shock.
- Locking pin track mechanism provides secure board-to-board or cable attachment.
- Durable PPS insulation supports repeated mating cycles in harsh environments.
Applications
- Industrial control systems requiring high durability
- Medical equipment demanding reliable interconnects
- Automotive electronics facing vibration and shock
Procurement Notes
Verify the specific suffix code against the manufacturer datasheet to confirm contact plating and housing material variations. Ensure the locking mechanism type matches the assembly requirements. Confirm RoHS compliance status for the specific production batch before procurement.
Selection Notes
Select this component for applications needing robust board-to-board connectivity with high cycle life. The 2mm pitch suits dense layouts. Verify that the 800V rating and current capacity meet circuit demands. Consider the vertical orientation for PCB stacking constraints.
Part Context
This part belongs to the Datamate J-Tek family, designed for safety-critical applications. It offers superior mechanical strength compared to standard connectors. The series is engineered for high-load conditions involving significant acceleration and impact forces.
Replacement Considerations
Direct substitutes within the same series include M80-8501045 and M80-8501046. Verify pin count and pitch compatibility when considering alternative models from other manufacturers.
FAQ
What is the contact material used in this connector?
The contacts are made of beryllium copper alloy to ensure high mechanical strength and conductivity.
Does this connector include a locking mechanism?
Yes, it features a locking pin track system for secure attachment during mating.
