M80-8631642

Overview

The M80-8631642 is a Datamate L-Tek series PCB header manufactured by Harwin Inc. It features a 16-position, double-row configuration with a 2mm (0.079 inch) pitch. Designed for vertical through-hole mounting, this male pin connector utilizes a friction latch mechanism and includes fully shrouded contacts. The assembly is constructed from black PPS insulation with gold-plated phosphor bronze terminals, ensuring reliable performance in board-to-board and wire-to-board applications.

Feature Summary

• Incorporates a friction latch system for secure mating retention
• Features fully shrouded contacts to prevent misalignment
• Utilizes polarized mouldings for correct orientation

Applications

• Board-to-board interconnects
• Wire-to-board connections
• Industrial control systems
• Consumer electronics assemblies

Procurement Notes

Verify the specific part number against official Harwin documentation to confirm the presence of the friction latch feature, as datasheet descriptions may vary between latch types. Ensure compatibility with corresponding female connectors within the Datamate L-Tek family before procurement. Cross-reference terminal plating specifications to meet environmental requirements.

Selection Notes

Select this component when a vertical, latched header is required for high-density connections. The 2mm pitch allows for compact circuit board layouts. Verify that the mating environment supports the friction latch mechanism and that the operating temperature range aligns with system demands.

Part Context

This connector belongs to the Datamate L-Tek family, known for robust mechanical performance. It serves as a male plug assembly designed to mate with specific female receptacles. The design emphasizes reliability in demanding environments through its shrouded contact structure and durable housing material.

Replacement Considerations

Compatible substitutes include other Harwin Datamate L-Tek headers with matching 16-pin counts and 2mm pitch. Ensure replacement parts maintain the same vertical orientation and through-hole termination style. Verify latch type compatibility if mechanical retention is critical.
