M80-8663405

$5.00

Description：CONN HEADER R/A 34POS 2MM
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Bulk,Tube

SKU:555e1e004538 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER R/A 34POS 2MM
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Bulk,Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：34
Number of Rows：2
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Latch Lock
Contact Length - Mating：-
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：-
Insulation Height：0.235" (5.97mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：-
Contact Material：Phosphor Bronze
Insulation Material：Polyester, Glass Filled
Features：Strain Relief Clips
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A per Contact
Voltage Rating：120V

Download product information

M80-8663405

Overview

The M80-8663405 is a Datamate J-Tek series header connector manufactured by Harwin Inc. It features a 34-position configuration with two rows of male pins arranged in a right-angle orientation for through-hole mounting. The connector utilizes a 2.00mm (0.079 inch) pitch and incorporates shrouded design elements to ensure proper alignment during mating. Constructed with polyphenylene sulfide (PPS) insulation, it supports operating temperatures ranging from -55°C to +125°C and meets UL 94 V-0 flammability standards.
