Product Detailed Parameters
- Description：CONN HEADER VERT 12POS 2MM
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Header
- Contact Type：Male Pin
- Pitch - Mating：0.079" (2.00mm)
- Number of Positions：12
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Shrouded - 4 Wall
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Latch Lock
- Contact Length - Mating：-
- Contact Length - Post：0.118" (3.00mm)
- Overall Contact Length：-
- Insulation Height：0.219" (5.56mm)
- Contact Shape：Circular
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：29.5µin (0.75µm)
- Contact Finish - Post：Tin-Lead
- Contact Material：Phosphor Bronze
- Insulation Material：Polyester, Glass Filled
- Features：-
- Operating Temperature：-55°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：2.2A
- Voltage Rating：800V
Download product information
Overview
The Harwin M80-8671222 is a Datamate L-Tek series male header connector featuring a 2mm pitch and 12 positions (6+6) in a double inline configuration. It utilizes through-board vertical mounting with solder pin termination. The contacts are constructed from beryllium copper with a gold finish, rated for 3A current and 800V voltage. Operating temperature ranges from -55°C to +125°C.
Feature Summary
- Features four-finger beryllium copper contacts designed for high reliability in industrial and military/aerospace applications.
- Incorporates locking latches that require specific tooling for engagement and disengagement.
- Provides shrouded design to ensure correct mating alignment and protection.
Applications
- High-end industrial equipment interconnects
- Military and aerospace systems
- Embedded system power and signal distribution
Procurement Notes
Verify the specific contact plating thickness and material composition against the official datasheet before integration. Confirm that the required latch tooling is available for assembly processes. Ensure PCB footprint dimensions match the specified through-board vertical termination style to guarantee mechanical stability.
Selection Notes
Select this component when high-reliability connections in harsh environments are required. The L-Tek series offers superior retention force compared to standard connectors. Consider the need for specialized tooling for the latch mechanism during design phase. Verify voltage and current ratings align with system requirements.
Part Context
This part belongs to the Harwin Datamate L-Tek family, known for robust performance in demanding sectors. It complements female receptacles and cable assemblies within the same 2mm pitch ecosystem. The series supports various stacking heights and configurations for complex board-to-board or cable-to-board connections.
Replacement Considerations
No direct public substitute part numbers are confirmed for this specific variant. Cross-model compatibility within the Datamate family requires verification of pitch, row count, and latch mechanisms.
FAQ
What material are the contacts made of?
The contacts are made of beryllium copper.
Does this connector require special tools for operation?
Yes, the locking latches require specific tooling for engagement and disengagement.
