M80-8672622

Overview

The M80-8672622 is a Datamate L-Tek header connector from Harwin Inc., designed for surface mount installation. It features a 2-row configuration with 6 positions and a 2.00mm mating pitch. The connector utilizes phosphor bronze contacts with gold plating, housed in black PPS insulation rated UL94 V-0. It supports a mating stack height of 14.25mm and operates within a temperature range of -55°C to +125°C.

Feature Summary

• High mechanical durability with 100G shock, 40G impact, and 10G vibration resistance
• Suitable for extreme environmental conditions ranging from -55°C to +125°C
• Surface mount design with friction lock retention

Applications

• Board repair where original transformers are difficult to source
• Powering up electronic units requiring robust interconnects
• Applications demanding high shock and vibration resistance

Procurement Notes

Verify the specific series designation (L-Tek vs J-Tek) against the official datasheet, as generic listings may lack precision. Confirm that the surface mount termination matches your PCB layout requirements. Ensure the 14.25mm stack height accommodates your assembly constraints. Check for RoHS compliance status if required by your manufacturing standards.

Selection Notes

Select this component when high mechanical resilience is critical for the application environment. The surface mount format is suitable for automated assembly processes. Verify that the 2.00mm pitch aligns with the mating connector specifications. Consider the operating temperature range to ensure reliability under thermal stress.

Part Context

This part belongs to the Harwin Datamate family, known for compact, high-density interconnect solutions. The M80 series specifically targets applications requiring robust performance in harsh environments. The L-Tek variant typically offers standard pin configurations suitable for general board-to-board connections.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing with other Harwin M80 series headers may be necessary if this specific variant is unavailable.
