M80-8760722

Overview

The M80-8760722 is a Datamate L-Tek series header connector manufactured by Harwin Inc. It features a single row with seven positions and a 2.00mm (0.079 inch) mating pitch. Designed for through-hole mounting, this right-angle male pin connector utilizes phosphor bronze contacts with tin plating on the tail and gold plating on the mating interface. The housing is constructed from black polyester reinforced with glass fiber, rated UL94 V-0. It supports board-to-board or cable applications within an operating temperature range of -55°C to +125°C.

Feature Summary

• Datamate L-Tek technology ensures high-reliability connections using four-finger beryllium copper contact design.
• Right-angle through-hole termination facilitates horizontal PCB integration with locking latches requiring tooling.
• Four-wall shrouded housing provides secure alignment and protection for the mating interface.

Applications

• Board-to-board interconnections in compact electronic assemblies
• Cable-to-board wiring harnesses requiring right-angle routing
• Industrial control systems demanding high-reliability signal transmission

Procurement Notes

Verify that the specific suffix '22' corresponds to the tin-plated tail configuration required for your soldering process. Confirm that the right-angle orientation matches your PCB layout constraints. Ensure that the necessary tooling is available for engaging the locking latches during assembly. Cross-reference the datasheet for precise mechanical dimensions to avoid clearance issues.

Selection Notes

Select this component when a right-angle, single-row male header is required for space-constrained designs. The 2.00mm pitch offers a balance between density and manufacturability. Consider the tin-plated tails for standard lead-free soldering compatibility. Evaluate the need for tooling-assisted locking mechanisms versus manual insertion requirements for your production line.

Part Context

This part belongs to the Datamate L-Tek family, known for robust performance in harsh environments. The M80-8760722 specifically addresses the need for right-angle connectivity within the 7-position variant lineup. It complements female counterparts in the same series to form complete interconnect solutions for mixed-signal applications.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Direct replacement requires matching the Datamate L-Tek series specifications, including the 7-position count, right-angle orientation, and through-hole termination style.

FAQ

What material is used for the contacts?

The contacts are made from phosphor bronze with a tin plating on the tail section and gold plating on the mating interface.

Does this connector require tooling for installation?

Yes, the M80-8760722 is fitted with locking latches that require specific tooling to engage properly during assembly.
