M80-8781722

$3.68

Description：CONN HEADER R/A 17POS 2MM
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Tube

SKU:813f2ebe3643 Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER R/A 17POS 2MM
Series：Datamate L-Tek
Mfr：Harwin Inc.
Package：Tube
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：17
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole, Right Angle
Termination：Solder
Fastening Type：Latch Holder
Contact Length - Mating：-
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：-
Insulation Height：0.156" (3.96mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：Tin-Lead
Contact Material：Phosphor Bronze
Insulation Material：Polybutylene Terephthalate (PBT), Glass Filled
Features：Strain Relief Clips
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A
Voltage Rating：120V

Download product information

M80-8781722

Overview

The Harwin M80-8781722 is a Datamate L-Tek header connector featuring 17 positions in a single row with a 2 mm pitch. It utilizes male pin contacts with tin/lead plating and phosphor bronze material. Designed for right-angle through-hole mounting, it incorporates a latch holder fastening mechanism. The unit operates within a temperature range of -55°C to +125°C and carries an electrical rating of 2.2 A.

Feature Summary

Incorporates a latch holder mechanism for secure mating retention
Features right-angle orientation for space-constrained board layouts
Utilizes phosphor bronze contacts with tin/lead surface finish

Applications

Right-angle board-to-board interconnections
High-density electronic assemblies requiring secure latching
Industrial control systems operating in extreme temperatures

Procurement Notes

Verify the specific tin/lead plating designation against current environmental regulations such as RoHS restrictions before procurement. Confirm that the right-angle form factor aligns with the mechanical constraints of the target PCB design. Ensure compatibility with the corresponding female socket series within the Datamate L-Tek family for proper engagement.

Selection Notes

Select this component when a single-row, right-angle configuration is required for high-reliability connections. The latch feature distinguishes it from unlatched variants, providing enhanced mechanical stability during vibration. Consider the 2.2 A current rating and 2 mm pitch to ensure adequate power handling and spacing for the application requirements.

Part Context

This part belongs to the Datamate L-Tek series, designed for harsh environments involving shock, vibration, and acceleration. The series emphasizes durability and high mating cycle endurance through four-finger beryllium copper contact technology, ensuring connection integrity under severe operational conditions.
