M80-8790722

Overview

The M80-8790722 is a Datamate L-Tek header connector manufactured by Harwin Inc. It features a vertical through-hole mounting style with 7 positions in a single row. The contact pitch is 2.00mm (0.079 inches). The contacts are male pins with tin plating, designed for solder termination. The housing is black, constructed from polyphenylene sulfide (PPS) reinforced with glass fiber, meeting UL94 V-0 flammability ratings. It operates within a temperature range of -55°C to +125°C and carries an unlatched configuration.

Feature Summary

• Vertical through-hole design for direct board integration
• Single-row shrouded housing for alignment security
• Tin-plated phosphor bronze contacts for reliable conductivity
• High-temperature resistant PPS insulation material

Applications

• Industrial control system interconnects
• Consumer electronics internal wiring
• Automotive electronic module connections
• Telecommunications equipment signal routing

Procurement Notes

Verify the specific datasheet version corresponding to the M80-8790722 part number before procurement. Confirm that the tin-plated contact finish aligns with your soldering process requirements. Ensure the vertical orientation and single-row layout match your PCB footprint specifications. Check for any recent product change notifications regarding material composition or manufacturing origin.

Selection Notes

Select this component when a vertical, unlatched header is required for space-constrained applications. The 2.00mm pitch allows for dense circuit layouts. Consider the tin plating for cost-effective soldering compared to gold finishes. Ensure the operating temperature range up to 125°C meets the environmental demands of the target assembly.

Part Context

This connector belongs to the Datamate L-Tek series, which is characterized by its compact size and robust mechanical locking capabilities when paired with compatible mates. The M80-8790722 represents a standard vertical header variant within this family, offering a balance between electrical performance and mechanical stability for general-purpose interconnect needs.

Replacement Considerations

Compatible substitutes include other Harwin Datamate L-Tek headers with identical 7-position, single-row, vertical configurations. Verify that alternative parts maintain the same 2.00mm pitch and through-hole termination style. Ensure mating connectors share the same shrouding and pin count to guarantee physical compatibility.
