M80-8820522

Overview

The Harwin M80-8820522 is a 5-position male pin header from the Datamate J-Tek series. It features a 2.00mm pitch and is designed for through-hole mounting. The connector utilizes gold-plated phosphor bronze contacts with a 4.5mm tail length. It supports vertical lateral locking via jackscrews, ensuring secure board-to-board or cable connections in compact applications.

Feature Summary

• Vertical orientation with lateral jackscrew locking mechanism
• Gold-plated phosphor bronze contacts for reliable conductivity
• Through-hole termination with 4.5mm tail length

Applications

• Compact board-to-board interconnects
• Cable-to-board connections
• Space-constrained electronic assemblies

Procurement Notes

Verify component obsolescence status prior to procurement as this part may be discontinued. Confirm availability of equivalent substitutes if production continuity is required. Validate mechanical dimensions against current design specifications to ensure compatibility with mating connectors and PCB layouts.

Selection Notes

Select this component for applications requiring vertical mounting with secure lateral locking. Ensure the design accommodates the 4.5mm tail length for through-hole soldering. Verify that the 2.00mm pitch matches the mating connector requirements and that the current rating meets system electrical demands.

Part Context

This component belongs to the Datamate J-Tek family, known for high-density interconnect solutions. The series offers various configurations including mixed gender options and different tail lengths. This specific model represents a standard male header variant within the broader connector ecosystem.

Replacement Considerations

• M80-8820525

FAQ

What is the locking mechanism for this connector?

It uses a vertical jackscrew system for lateral locking to secure the connection.

What is the contact material?

The contacts are made of phosphor bronze with a gold plating finish.
