M80-8870601

Overview

The Harwin M80-8870601 is a Datamate L-Tek series receptacle connector featuring a 2x3 (6 position) female contact layout. It utilizes a 2mm pitch and employs vertical through-hole termination for PCB mounting. The contacts are gold-plated, while the post finish is tin-lead. This component supports a voltage rating of 800V and offers mated stacking heights of 7.23mm and 7.85mm.

Feature Summary

• Vertical through-hole design for direct PCB integration
• Gold-plated female contacts with tin-lead post finish
• High voltage rating of 800V for robust electrical performance

Applications

• Automotive electronic systems
• General purpose industrial interconnects
• Military grade circuit assemblies

Procurement Notes

Verify the specific tin-lead post finish against environmental compliance requirements such as RoHS restrictions before procurement. Confirm that the vertical orientation and specified stacking heights align with the mechanical constraints of the target printed circuit board assembly to ensure proper mating.

Selection Notes

Select this part when a low-profile vertical female connector is required for high-voltage applications. The Datamate L-Tek series provides reliable friction latch retention. Ensure the application environment accommodates the tin-lead post material if lead-free alternatives are mandated by project specifications.

Part Context

This component belongs to the Datamate L-Tek family, designed for mixed-signal and power applications. It complements male headers within the same series, offering a compact solution for board-to-board or cable-to-board connections in space-constrained environments requiring secure mechanical locking.

Replacement Considerations

M80-8870605
