Product Detailed Parameters
- Description：CONN RCPT 4POS 0.079 GOLD PCB
- Series：Datamate L-Tek
- Mfr：Harwin Inc.
- Package：Tube
- Connector Type：Receptacle
- Contact Type：Female Socket
- Style：Board to Board or Cable
- Number of Positions：4
- Number of Positions Loaded：All
- Pitch - Mating：0.079" (2.00mm)
- Number of Rows：2
- Row Spacing - Mating：0.079" (2.00mm)
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Locking Ramp
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：12.0µin (0.30µm)
- Insulation Color：Black
- Insulation Height：0.202" (5.14mm)
- Contact Length - Post：0.118" (3.00mm)
- Operating Temperature：-55°C ~ 125°C
- Material Flammability Rating：UL94 V-0
- Contact Finish - Post：Gold
- Mated Stacking Heights：7.23mm, 7.85mm
- Ingress Protection：-
- Features：-
- Current Rating (Amps)：-
- Voltage Rating：800V
Download product information
Overview
The M80-8874405 is a 4-position female socket connector from the Harwin Datamate Mix-Tek series. It features a 2.00mm (0.079 inch) pitch and is designed for vertical through-hole mounting with PC tail termination. The assembly utilizes beryllium copper contacts with gold plating, housed in black polyphenylene sulfide (PPS). Rated for 800V and operating within a temperature range of -55°C to +125°C, it provides robust performance in demanding environments.
Feature Summary
- Datamate Mix-Tek series offering high mechanical resilience including shock and vibration resistance
- Vertical through-hole PC tail design for secure board integration
- Gold-plated beryllium copper contacts ensuring reliable signal transmission
- High voltage rating of 800V with thermal stability up to 125°C
Applications
- Industrial control systems requiring high vibration resistance
- Automotive electronics applications
- Medical device interconnections
- Aerospace and defense equipment
Procurement Notes
Verify the specific part number M80-8874405 against official Harwin documentation to confirm compatibility with mating headers. Ensure that the required contact count and termination style match the design specifications. Cross-reference datasheets for environmental ratings and material certifications before finalizing procurement decisions.
Selection Notes
Select this component when a compact, high-reliability connector is needed for vertical PCB mounting. The Datamate Mix-Tek series is suitable for applications demanding superior mechanical strength and electrical performance. Consider the 2.00mm pitch and 800V rating when designing circuits that require robust isolation and durability.
Part Context
This connector belongs to the Datamate family, known for its modular design and high-density capabilities. The Mix-Tek variant specifically emphasizes mechanical ruggedness, making it distinct from standard series. It is part of a broader ecosystem of compatible headers and accessories provided by Harwin Inc.
Replacement Considerations
Public confirmed substitute part numbers are not available in the provided source data. Verify compatibility with mating components before considering alternative sources or generic equivalents.
FAQ
What is the voltage rating of the M80-8874405?
The M80-8874405 has a voltage rating of 800V.
What is the operating temperature range for this connector?
The connector operates within a temperature range of -55°C to +125°C.
