M80-8970401

Overview

The M80-8970401 is a Datamate L-Tek series receptacle connector manufactured by Harwin Inc. It features a dual-in-line configuration with 7 positions, designed for through-hole board mounting. The connector utilizes female socket contacts made from beryllium copper, finished with a gold plating to ensure reliable signal transmission and corrosion resistance. It operates within a voltage rating of 800V and supports current ratings up to 3A per contact. The housing is constructed from black polyphenylene sulfide (PPS), providing high thermal stability and mechanical strength. This component is part of the broader Datamate ecosystem, offering robust interconnection solutions for industrial applications.

Feature Summary

• Dual-in-line female socket design for secure mating
• Gold-plated beryllium copper contacts for durability
• Through-hole termination method for PCB integration
• High-temperature resistant PPS polymer housing

Applications

• Industrial control systems requiring high-voltage isolation
• Military-grade electronic assemblies
• General-purpose power distribution boards
• Automotive electronics interfaces

Procurement Notes

Verify component status carefully as this specific part number is listed as obsolete and no longer manufactured by Harwin Inc. Sourcing may require checking secondary distributors or confirming availability of legacy stock. Ensure that any substitute components meet the original electrical and mechanical specifications before integration into production designs.

Selection Notes

Select this connector when a 7-position, 2mm pitch female header is required for through-hole assembly. Consider the Datamate L-Tek series compatibility if mating with corresponding male pins. Evaluate the 800V rating and 3A current capacity against circuit requirements. Confirm that the operating temperature range aligns with the environmental conditions of the target application.

Part Context

This component belongs to the Datamate Mix-Tek and L-Tek families from Harwin Inc., known for their compact size and high reliability. The M80 series represents a standard line of connectors used in various sectors including aerospace and telecommunications. The specific model indicates a 7-pin configuration within this modular system.

Replacement Considerations

Public confirmed substitute part numbers are not explicitly provided in the source data for direct replacement. Users should consult Harwin's official obsolescence notices or distributor recommendations for equivalent active parts that match the 7-position, 2mm pitch, female socket specifications.
