M83-LFT1F4N27-0000-000

Overview

The Harwin M83-LFT1F4N27-0000-000 is a Datamate J-Tek cable assembly featuring a 27-position, 3-row female receptacle. It utilizes 22 AWG wire with a 250mm length and double-ended configuration. The connector employs jackscrews for secure mating and is designed for through-hole termination. This component belongs to the high-reliability Datamate series, engineered for robust performance in demanding electronic interconnect applications requiring durable mechanical retention.

Feature Summary

• Features jackscrew locking mechanism for secure connection retention
• Constructed with 22 AWG copper conductors for signal integrity
• Utilizes gold-plated contacts to ensure reliable electrical performance
• Designed with a 3-row female housing for compact multi-circuit integration

Applications

• Industrial control systems requiring vibration-resistant connections
• Medical equipment needing high-reliability interconnects
• Test and measurement instrumentation interfaces
• Automotive electronics subsystems

Procurement Notes

Verify the specific jack screw type and contact plating thickness against project requirements before ordering. Confirm that the 250mm cable length and double-ended configuration align with spatial constraints. Ensure compatibility with the corresponding male header part number within the Datamate J-Tek series. Check for any RoHS or REACH compliance documentation relevant to the manufacturing batch.

Selection Notes

Select this model when a pre-assembled cable solution is preferred over discrete components. The 22 AWG gauge supports moderate current loads while maintaining flexibility. The 3-row layout maximizes pin density within a small footprint. Consider the through-hole mounting style for permanent board attachment. Evaluate the jackscrew option if superior mechanical security is required over standard latches.

Part Context

This component is part of the Datamate J-Tek family, known for its high-density interconnect capabilities. The series offers various row configurations and termination styles. The M83 prefix indicates a specific housing variant within the broader Harwin connector portfolio. It complements matching male headers to form complete board-to-wire assemblies.

Replacement Considerations

Direct substitutes include other Harwin Datamate J-Tek cable assemblies with identical 27-position, 3-row female specifications. Verify that alternative parts maintain the same 22 AWG wire gauge and 250mm length. Ensure the replacement also features jackscrew retention and compatible PCB footprint dimensions.
