M83-LML3M5N25-0101-333

Overview

The M83-LML3M5N25-0101-333 is a Datamate J-Tek header connector manufactured by Harwin. It features a 2 mm pitch and a 3-row configuration with 25 positions. The component utilizes male pin contacts made of phosphor bronze with gold plating. Termination is achieved via right-angle solder pins with a 4 mm tail length, designed for through-hole mounting. The product belongs to the Datamate series and is classified under headers and wire housings.

Feature Summary

• Datamate J-Tek series construction with mixed contact capabilities
• Right-angle solder termination with extended 4 mm tails
• Gold-plated phosphor bronze male contacts for reliable connection

Applications

• Board-to-board interconnection systems
• Industrial control panel assemblies
• Electronic equipment internal wiring

Procurement Notes

Verify part authenticity against official Harwin documentation before acquisition. Confirm RoHS compliance status through current environmental declarations. Check for obsolescence notices as this specific variant may have limited availability. Ensure soldering processes match the specified tail dimensions for proper mechanical retention.

Selection Notes

Select this component when right-angle through-hole mounting is required for high-density connections. The 4 mm tail length accommodates thicker PCBs or provides strain relief. Gold plating ensures durability in demanding environments. Verify that the 25-position count matches the circuit design requirements.

Part Context

This connector is part of the Datamate J-Tek family, known for high-reliability applications. The M83 prefix indicates a custom or specific configuration within the broader Harwin portfolio. It complements female counterparts in the same series to form complete mating pairs for robust signal transmission.

Replacement Considerations

No public confirmed substitute part numbers are available for this specific configuration.
