M83-LMT1M2N18-0000-000

$15.26

Description：CONN HEADER VERT 18POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tray

SKU:e1e256678d3e Category: Headers, Male Pins Brand: Harwin Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER VERT 18POS 2MM
Series：Datamate J-Tek
Mfr：Harwin Inc.
Package：Tray
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.079" (2.00mm)
Number of Positions：18
Number of Rows：3
Row Spacing - Mating：0.079" (2.00mm)
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Shrouded - 4 Wall
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Threaded
Contact Length - Mating：-
Contact Length - Post：0.126" (3.20mm)
Overall Contact Length：-
Insulation Height：0.240" (6.10mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：-
Contact Material：Phosphor Bronze
Insulation Material：Polyphenylene Sulfide (PPS), Glass Filled
Features：Mating Flange, Mounting Flange, Mounting Hardware
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.2A per Contact
Voltage Rating：120V

Download product information

M83-LMT1M2N18-0000-000

Overview

The M83-LMT1M2N18-0000-000 is a Datamate J-Tek board connector from Harwin Inc. It features 18 contacts arranged in a single row with male pin terminals. The connector utilizes a straight, surface-mount soldering termination method for PCB integration. It operates within the Datamate series, designed for high-reliability interconnect applications requiring secure mating and robust mechanical performance.

Feature Summary

Datamate J-Tek series design for high-reliability interconnects
Single-row configuration with 18 male contact positions
Straight surface-mount solder tail termination
Jackscrew locking mechanism for secure mating retention

Applications

Industrial control systems
Medical equipment
Defense and aerospace electronics
Metering and measurement devices

Procurement Notes

Verify the specific ordering suffix to confirm contact plating, jack screw type, and mounting style. Ensure the selected variant matches the required current rating and voltage specifications for the target application. Cross-reference the manufacturer datasheet for precise dimensional tolerances and reflow soldering profiles to guarantee reliable assembly and long-term operational integrity.

Selection Notes

Select this component when a single-row, surface-mount male header is required for compact PCB layouts. The Datamate J-Tek system offers versatile mating options including cable assemblies and back-to-back configurations. Consider the jack screw feature if vibration resistance and secure connection retention are critical for the deployment environment.

Part Context

This part belongs to the Datamate J-Tek family, known for its modular design and high reliability in harsh environments. The series supports various contact counts and termination styles, allowing engineers to standardize on a single connector platform across different product lines while maintaining consistent mechanical and electrical performance characteristics.
