M83-LMT1M2N60-0000-000

Overview

The M83-LMT1M2N60-0000-000 is a 60-position male header from the Harwin Datamate J-Tek series. It features a 3-row configuration with a 2mm pitch and vertical orientation. The connector utilizes through-hole solder termination with a 4mm tail length and includes integrated jackscrews for secure board mounting. Rated for 120V and 2.2A per contact, it operates within a temperature range of -55°C to 125°C. The housing is black PPS material rated UL94 V-0, with gold-plated beryllium copper contacts.

Feature Summary

• Integrated jackscrew system provides stable mechanical locking between mating connectors
• Shrouded design ensures correct alignment and prevents pin misinsertion
• Vertical through-hole termination with extended tail facilitates automated assembly
• Gold-plated contacts ensure reliable signal transmission in demanding environments

Applications

• Industrial control systems requiring robust board-to-board connections
• Test and measurement equipment needing secure interconnects
• Automotive electronics applications with high vibration exposure
• Medical devices requiring reliable signal integrity

Procurement Notes

Verify the specific suffix codes against official Harwin documentation to confirm exact tail length, contact plating, and jack screw inclusion. Ensure compatibility with corresponding female receptacles from the same Datamate J-Tek family. Confirm RoHS compliance status through current manufacturer declarations. Cross-reference ordering numbers with distributor catalogs to avoid variant mismatches.

Selection Notes

Select this component when a high-density 60-pin vertical interface is required with mechanical locking capability. The 2mm pitch allows for compact board layouts while maintaining adequate spacing. Consider the 4mm tail length for PCB thickness and component clearance requirements. Evaluate the 2.2A current rating against total system load distribution across all rows.

Part Context

This part belongs to the Datamate J-Tek M83 series, designed for high-reliability interconnect solutions. The series is characterized by durable jackscrews and versatile mounting options. It serves as a male header counterpart to female receptacles in the same ecosystem, enabling modular connection architectures for complex electronic assemblies.

Replacement Considerations

Direct substitutes include other 60-position 3-row headers from the Datamate J-Tek family with matching 2mm pitch and vertical orientation. Verify equivalent electrical ratings and mechanical dimensions before substitution. Alternative Harwin variants may differ in tail length or contact plating specifications.
