MA-406 32.0000MC-C0:ROHS

Crystals Overview

The MA-406 32.0000MC-C0:ROHS is a surface-mount AT-cut crystal oscillator manufactured by Epson Timing. It operates at a nominal frequency of 32 MHz with a load capacitance of 18 pF. The component features a frequency tolerance of 20 ppm and a stability of 30 ppm. It is housed in an 8 mm x 3.8 mm SMD package, with physical dimensions of 8 mm length, 3.2 mm width, and 2.54 mm height. The device supports a minimum operating temperature of -20°C and a maximum of +70°C. Equivalent series resistance (ESR) is 60 Ohms, and the recommended drive level is 100 uW.

Crystals Feature Summary

• AT-cut resonator technology for stable oscillation
• Surface-mount design compatible with automated assembly
• RoHS compliant construction

Crystals Applications

• General-purpose clock generation in embedded systems
• Timing reference for microcontrollers and processors
• Communication interface synchronization

Crystals Procurement Notes

Verify part authenticity through authorized Epson distributors or direct manufacturer channels. Confirm RoHS compliance status via current datasheets. Check for end-of-life notifications as discontinuation may affect long-term supply. Ensure storage conditions meet specified environmental limits to maintain performance integrity prior to installation.

Crystals Selection Notes

Select this component when a 32 MHz frequency is required with specific load capacitance matching circuit design. Verify that the operating temperature range meets application environmental requirements. Ensure PCB footprint accommodates the 8 mm x 3.8 mm package dimensions. Confirm drive level specifications align with system power constraints.

Crystals Part Context

This model belongs to the MA-406 series of surface-mount crystals from Epson Timing. The series offers various frequency options within similar physical form factors. The MA-406 designation indicates a standard AT-cut crystal optimized for general electronic applications requiring precise timing references in compact designs.

Crystals Replacement Considerations

Direct substitutes include ECS-60-18-7SX-TR from ECS Inc. for related discontinued variants. Verify electrical parameters and mechanical dimensions before substitution. Consult official Epson documentation for approved alternative part numbers.
