MAAD-011045-TR0500

Overview

The MAAD-011045-TR0500 is a wideband digital step attenuator from MACOM Technology Solutions, operating across a frequency range of 0 Hz to 18 GHz. This component provides an attenuation value ranging from 0.5 dB to 31.5 dB with a least significant bit (LSB) step of 0.5 dB. It is housed in a lead-free 3mm 20-lead surface mount plastic package with an exposed pad for thermal management. The device features consistent phase characteristics and is designed for high reliability in RF applications.

Feature Summary

• Wideband operation covering DC to 18 GHz
• 6-bit resolution with 0.5 dB LSB step size
• Lead-free 3mm 20-lead surface mount package
• Consistent phase response across the frequency range

Applications

• Wireless communication systems
• Test and measurement equipment
• Military and aerospace radar systems
• Satellite communication links

Procurement Notes

Verify the specific suffix TR0500 indicates the tape and reel packaging configuration with a quantity of 500 units per reel. Confirm moisture sensitivity level requirements for storage and handling prior to assembly. Ensure the 3mm 20-lead footprint matches the target PCB design. Check for RoHS compliance documentation if required by project specifications.

Selection Notes

Select this component when a wide bandwidth up to 18 GHz is required with fine 0.5 dB control steps. The 6-bit resolution offers 64 distinct attenuation states suitable for precise signal level adjustment. Consider the 3mm 20-lead package for compact board space constraints. Evaluate thermal performance needs due to the exposed pad design for heat dissipation.

Part Context

This part belongs to MACOM's MAAD series of MMIC digital attenuators. These devices are engineered for high linearity and low insertion loss. The series includes various pin counts and package sizes to accommodate different integration needs. The MAAD-011045 specifically targets applications requiring broad frequency coverage and stable phase performance.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data. Consult MACOM official documentation for potential cross-reference options or newer generation replacements.
