Aluminum Electrolytic Capacitors MAL229960681E3 product image

MAL229960681E3

$45.06

Description：CAP ALUM 680UF 20% 550V LEAD TH
Series：299 PHL-4TSI
Mfr：Vishay Beyschlag/Draloric/BC Components
Package：Box

SKU:5bddc1820c30 Category: Aluminum Electrolytic Capacitors Brand: Vishay Beyschlag/Draloric/BC Components

ChipApex WhatsApp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MAL229960681E3 is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Vishay Beyschlag/Draloric/BC Components. Its product description is CAP ALUM 680UF 20% 550V LEAD TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for MAL229960681E3

Description：CAP ALUM 680UF 20% 550V LEAD TH
Series：299 PHL-4TSI
Mfr：Vishay Beyschlag/Draloric/BC Components
Package：Box
Capacitance：680 µF
Tolerance：±20%
Voltage - Rated：550 V
ESR (Equivalent Series Resistance)：210mOhm @ 100Hz
Lifetime @ Temp.：5000 Hrs @ 105°C
Operating Temperature：-40°C ~ 105°C
Polarization：Polar
Ratings：-
Applications：General Purpose
Ripple Current @ Low Frequency：3.35 A @ 100 Hz
Ripple Current @ High Frequency：5.025 A @ 10 kHz
Lead Spacing：0.886" (22.50mm)
Size / Dimension：1.575" Dia (40.00mm)
Height - Seated (Max)：2.441" (62.00mm)
Surface Mount Land Size：-
Mounting Type：Through Hole
Package / Case：Radial, Can - Snap-In - 4 Lead
Impedance：165 mOhms

Aluminum Electrolytic Capacitors datasheet and documents for MAL229960681E3
