MAX16024PTBS18+

Supervisors Overview

The MAX16024PTBS18+T is a single-channel voltage supervisor manufactured by Analog Devices Inc./Maxim Integrated. It operates within a supply voltage range of 1.7V to 5.5V and features an adjustable threshold voltage, specifically configured at 1.8V for this variant. The device provides a push-pull/totem pole output with active-low reset assertion. Key timing specifications include a minimum reset timeout of 145ms. It is housed in a 10-TDFN (3x3) surface-mount package and supports operation across an extended temperature range from -40°C to +85°C.

Supervisors Feature Summary

• Provides precise power supply monitoring with an adjustable threshold voltage for flexible system integration.
• Features a dedicated push-pull output stage capable of driving load currents directly without external components.
• Ensures reliable system recovery through a guaranteed minimum reset timeout period following power-up or fault conditions.

Supervisors Applications

• Battery backup circuitry in low-power electronic devices
• Voltage supervision for embedded microprocessor systems
• Power management in portable consumer electronics

Supervisors Procurement Notes

Verify the exact suffix against official documentation, as variations may indicate different thresholds or packages. Confirm RoHS compliance status and lead times directly with authorized distributors. Ensure the ordering part number matches the required voltage threshold and package type specified in the design.

Supervisors Selection Notes

Select this component when a single-channel supervisor with an adjustable threshold is required for voltages between 1.7V and 5.5V. Consider the 145ms minimum timeout if fast system recovery is not critical. The TDFN package suits space-constrained designs requiring surface-mount technology.

Supervisors Part Context

This part belongs to the MAX16024 family of voltage supervisors designed for battery-powered applications. The series offers configurable thresholds and robust reset generation, making it suitable for maintaining system integrity during power fluctuations in portable and industrial equipment.

Supervisors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Consult manufacturer cross-reference guides for potential alternatives.
