MAX16162NDK300+

Supervisors Overview

The MAX16162NDK300+ is a micropower supervisor IC designed for low-voltage IoT applications. It monitors input voltage and asserts a reset output when the voltage falls below a specific threshold. The device features an independent VCC supply pin, allowing operation with separate logic and monitor supplies. Key electrical parameters include a typical quiescent current of 825 nA to extend battery life, a reset threshold range from 0.6 V to 4.85 V, and multiple selectable reset timeout periods. It operates within a temperature range of -40°C to +125°C.

Supervisors Feature Summary

• Glitch-free reset generation ensures reliable microcontroller initialization without false triggers during power transitions.
• Ultra-low static current consumption significantly extends battery operating life in portable and wearable devices.
• Independent VCC and VIN inputs allow flexible power management by separating the monitored rail from the logic supply.

Supervisors Applications

• Low-voltage microcontrollers and microprocessors
• Portable and battery-powered equipment
• Wearable accessories and electronic readers

Supervisors Procurement Notes

Verify the exact suffix NDK300 against the manufacturer's official datasheet to confirm the specific reset threshold voltage and package configuration. Ensure compatibility with system voltage requirements before integration. Check current availability status as distribution may vary.

Supervisors Selection Notes

Select this component for designs requiring minimal standby current and robust protection against brown-out conditions. The wide threshold range allows customization for various logic families. Verify that the required reset delay meets the target processor's startup timing specifications.

Supervisors Part Context

This part belongs to the MAX16162 family of micropower supervisors from Analog Devices/Maxim Integrated. These ICs are engineered for space-constrained applications where power efficiency is critical. The series provides essential power management functions in compact packages suitable for modern mobile electronics.

Supervisors Replacement Considerations

Consult official substitution guides for equivalent supervisors with similar quiescent current and threshold ranges. Verify pinout compatibility if replacing in existing layouts. Ensure thermal performance matches the application environment.
