MAX20323DENC+

Power Management - Specialized Overview

The MAX20323DENC+ is a specialized power management IC designed as a USB Type-C CC-pin overvoltage protector. It operates within a supply voltage range of 2.5V to 5.5V and draws a supply current between 35µA and 170µA. The device functions reliably across an operating temperature range of -40°C to +85°C (TA). It is housed in a compact 12-WLP package measuring 1.7x1.32mm, suitable for surface-mount assembly.

Power Management - Specialized Feature Summary

• Provides dedicated overvoltage protection for USB Type-C CC pins
• Supports flexible system design with wide operating supply voltage range
• Low quiescent current consumption for efficient power management

Power Management - Specialized Applications

• Smart Phones
• Tablets
• Mobile Communications Devices

Power Management - Specialized Procurement Notes

Verify availability status carefully as this component may be subject to limited supply or factory special order conditions. Confirm the exact ordering suffix matches the required package variant. Ensure compliance with RoHS standards and check for any specific handling requirements associated with the WLP package type during procurement.

Power Management - Specialized Selection Notes

Select this component when robust overvoltage protection for USB Type-C communication lines is required. Consider the 12-WLP footprint for space-constrained designs. Verify that the 2.5V to 5.5V input range aligns with the system's power architecture. Evaluate the low standby current benefits for battery-operated mobile applications.

Power Management - Specialized Part Context

This part belongs to the MAX20323 family of power management integrated circuits from Analog Devices/Maxim Integrated. It serves as a specialized solution for protecting sensitive USB Type-C interfaces from voltage spikes. The DENC+ suffix indicates the specific tape-and-reel packaging and lead-free composition compliant with environmental directives.

Power Management - Specialized Replacement Considerations

Consult official manufacturer substitution guides for verified alternatives. Generic cross-references are not recommended due to specific pinout and electrical characteristic dependencies. Verify compatibility with existing PCB footprints if considering alternative packages within the same functional family.
