MAX2163AETL+T

Overview

The MAX2163AETL+T is an integrated tuner designed for ISDB-T low-IF reception. It operates within the 470MHz to 770MHz frequency range, supporting single-segment tuning capabilities. The component utilizes a direct-conversion architecture to downconvert RF signals to a low intermediate frequency. It is housed in a compact 40-TQFN (6x6) package suitable for surface-mount applications. The device supports supply voltages ranging from 2.7V to 3.3V and functions reliably across an industrial temperature range of -40°C to +85°C.

Feature Summary

• Integrated low-IF tuner architecture optimized for ISDB-T standards
• Direct-conversion signal processing for efficient frequency downconversion
• Single-segment tuning capability for digital terrestrial television reception

Applications

• ISDB-T digital terrestrial television receivers
• Portable mobile devices requiring broadcast reception
• Embedded TV tuner modules

Procurement Notes

Verify current availability status as this component may be subject to limited supply or discontinuation notices. Confirm that the specific suffix matches the required operational specifications. Check for official End-of-Life notifications or product change notices prior to finalizing procurement plans to ensure long-term project viability.

Selection Notes

Select this component when designing systems specifically compliant with ISDB-T standards. Ensure the design accommodates the 40-TQFN package dimensions and thermal requirements. Verify that the system power supply aligns with the specified voltage ranges and that the target application falls within the designated frequency band constraints.

Part Context

This part belongs to the Maxim Integrated line of RF tuners, specifically engineered for mobile and portable multimedia applications. It represents a specialized solution for digital video broadcasting, integrating complex RF front-end functions into a single compact package to minimize board space and simplify system design.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Due to the specialized nature of ISDB-T low-IF tuners, alternative components must be evaluated based on functional compatibility and standard support rather than direct pin-to-pin substitution.
