MAX4784EGE

$2.23

Description：IC SWITCH SPDT X 4 1OHM 16QFN
Series：-

SKU:38028526e593 Category: Analog Switches, Multiplexers, Demultiplexers Brand: Analog Devices Inc./Maxim Integrated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MAX4784EGE is listed in the Analog Switches, Multiplexers, Demultiplexers range at ChipApex. The manufacturer field lists Analog Devices Inc./Maxim Integrated. Its product description is IC SWITCH SPDT X 4 1OHM 16QFN. Review the specifications below when checking this part for your BOM.

Analog Switches, Multiplexers, Demultiplexers specifications for MAX4784EGE

Description：IC SWITCH SPDT X 4 1OHM 16QFN
Series：-
Mfr：Analog Devices Inc./Maxim Integrated
Package：Tube,Tube
Switch Circuit：SPDT
Multiplexer/Demultiplexer Circuit：2:01
On-State Resistance (Max)：1Ohm
Channel-to-Channel Matching (ΔRon)：100mOhm
Voltage - Supply, Single (V+)：1.6V ~ 4.2V
Voltage - Supply, Dual (V±)：-
Switch Time (Ton, Toff) (Max)：25ns, 10ns
-3db Bandwidth：123MHz
Charge Injection：5pC
Channel Capacitance (CS(off), CD(off))：33pF, 60pF
Current - Leakage (IS(off)) (Max)：1nA
Crosstalk：-95dB @ 1MHz
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：16-VQFN Exposed Pad
Supplier Device Package：16-QFN (4x4)
Number of Circuits：4

Analog Switches, Multiplexers, Demultiplexers datasheet and documents for MAX4784EGE

MAX4784EGE

Analog Switches, Multiplexers, Demultiplexers Overview

The MAX4784EGE is a quad 2:1 analog multiplexer in a 16-pin Thin QFN package. It operates from a single +1.6V to +4.2V supply and features fast switching speeds with tON = 20ns and tOFF = 8ns. The device handles rail-to-rail analog signals while consuming less than 1µW of quiescent power. At a +2.7V supply, it provides low on-resistance (RON) of 0.7Ω and RON flatness of 0.1Ω. The digital logic inputs are compatible with +1.8V CMOS logic when using a single +3V supply.

Analog Switches, Multiplexers, Demultiplexers Feature Summary

Quad 2:1 analog multiplexing architecture
Low on-resistance and high signal integrity
Ultra-low quiescent power consumption
+1.8V CMOS logic input compatibility

Analog Switches, Multiplexers, Demultiplexers Applications

Power routing
Battery-powered systems
Audio and video signal routing
Low-voltage data-acquisition systems
PCMCIA cards

Analog Switches, Multiplexers, Demultiplexers Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm package type and temperature range. Confirm that the component matches the exact part number specifications before procurement. Ensure compliance with relevant industry standards for the intended application environment.

Analog Switches, Multiplexers, Demultiplexers Selection Notes

Select this component for applications requiring low voltage operation and minimal power consumption. Consider the 16-pin Thin QFN package for space-constrained designs. Verify that the analog signal range aligns with the single-supply voltage capabilities of the device.

Analog Switches, Multiplexers, Demultiplexers Part Context

The MAX4784EGE belongs to the MAX4780/MAX4784 family of low on-resistance, low-voltage, quad 2:1 analog multiplexers. These devices are designed for portable and battery-operated applications where power efficiency and signal fidelity are critical requirements.
