MAX4968CEXB+T

$39.23

Description：IC SW SPST-NOX16 34OHM 64CTBGA
Series：-

SKU:cdd645c78195 Category: Analog Switches, Multiplexers, Demultiplexers Brand: Analog Devices Inc./Maxim Integrated

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MAX4968CEXB+T is listed in the Analog Switches, Multiplexers, Demultiplexers range at ChipApex. The manufacturer field lists Analog Devices Inc./Maxim Integrated. Its product description is IC SW SPST-NOX16 34OHM 64CTBGA. Review the specifications below when checking this part for your BOM.

Analog Switches, Multiplexers, Demultiplexers specifications for MAX4968CEXB+T

Description：IC SW SPST-NOX16 34OHM 64CTBGA
Series：-
Mfr：Analog Devices Inc./Maxim Integrated
Package：Tape & Reel (TR)
Switch Circuit：SPST - NO
Multiplexer/Demultiplexer Circuit：1:01
On-State Resistance (Max)：34Ohm
Channel-to-Channel Matching (ΔRon)：1.02Ohm
Voltage - Supply, Single (V+)：10V ~ 12.5V
Voltage - Supply, Dual (V±)：-
Switch Time (Ton, Toff) (Max)：5µs, 3.5µs
-3db Bandwidth：30MHz
Charge Injection：150pC
Channel Capacitance (CS(off), CD(off))：8pF
Current - Leakage (IS(off)) (Max)：-
Crosstalk：-69dB @ 5MHz
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：64-LFBGA
Supplier Device Package：64-CTBGA (7x7)
Number of Circuits：16

Analog Switches, Multiplexers, Demultiplexers datasheet and documents for MAX4968CEXB+T

MAX4968CEXB+T

Analog Switches, Multiplexers, Demultiplexers Overview

The MAX4968CEXB+T is a 16-channel, high-voltage analog switch in a 64-bump BGA package. It features SPST configuration with 34Ω max on-resistance and operates from -40°C to +85°C. Logic supply voltage ranges from 2.37V to 5.5V, while the positive supply is 10V to 12.5V and negative supply is 0V to -200V. Turn-on time is 5µs max and turn-off time is 3.5µs max. The device includes integrated 40kΩ bleed resistors for capacitive load discharge.

Analog Switches, Multiplexers, Demultiplexers Feature Summary

Integrated 40kΩ bleed resistors on each switch terminal to discharge capacitive loads
Daisy-chainable serial interface with asynchronous set/clear inputs for simultaneous control
HVCMOS process technology providing latch-free robustness and integrated overvoltage protection

Analog Switches, Multiplexers, Demultiplexers Applications

Medical Ultrasound Imaging
Nondestructive Testing (NDT)
Industrial Printing

Analog Switches, Multiplexers, Demultiplexers Procurement Notes

Verify the specific suffix 'EXB' corresponds to the 64-bump BGA package variant when sourcing. Confirm RoHS compliance status through official manufacturer documentation or authorized distributors. Ensure the component matches the exact part number to guarantee correct pinout and electrical characteristics.

Analog Switches, Multiplexers, Demultiplexers Selection Notes

Select this model when integrated bleed resistors are required for piezoelectric transducer applications. Compare against the MAX4968BEXB+T if external discharge paths are preferred. Verify that the 64-bump BGA footprint fits the design constraints compared to LQFP alternatives.

Analog Switches, Multiplexers, Demultiplexers Part Context

This component belongs to the MAX4968 family of high-voltage analog switches. The 'C' designation indicates the inclusion of internal bleed resistors, distinguishing it from the 'B' variant which lacks them. Both variants share identical switching performance and packaging specifications.
