MAX6023EBT12+

Overview

The MAX6023EBT12+ is a precision series voltage reference manufactured by Analog Devices Inc./Maxim Integrated. It provides a fixed output voltage of 1.2V with an initial accuracy of 0.24%. The device operates within an input voltage range of up to 12.6V and features a temperature coefficient of 30 PPM/C. It is designed for low-power applications, utilizing a UCSP-5 surface-mount package suitable for space-constrained designs.

Feature Summary

• Delivers high-precision voltage regulation with tight initial accuracy tolerances.
• Engineered for low-power consumption in portable and battery-operated systems.
• Features a compact UCSP-5 footprint to minimize printed circuit board area.

Applications

• Portable instrumentation requiring stable reference voltages
• Battery-powered measurement devices
• Data acquisition systems

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and specific lot traceability requirements before procurement. Ensure the ordering suffix matches the required tape-and-reel packaging configuration for automated assembly processes.

Selection Notes

Select this component when a fixed 1.2V reference with 0.24% accuracy is required. Consider the 30 PPM/C temperature coefficient for thermal stability needs. The UCSP-5 package is optimal for high-density layouts where space is limited compared to standard SOT packages.

Part Context

This part belongs to the MAX6023 series of precision, low-power, low-dropout voltage references. The series is characterized by its ability to provide stable outputs in small form factors, catering to modern electronic design trends that prioritize miniaturization without sacrificing electrical performance.

Replacement Considerations

Consult official datasheets for pin-compatible alternatives within the same series. Verify that substitute parts match the 1.2V output, 0.24% accuracy, and UCSP-5 package constraints.
