MAX77658AANX+T

Power Management - Specialized Overview

The MAX77658AANX+T is an ultra-low power PMIC from Analog Devices, designed for battery management in size-constrained applications. It integrates a single-input charger and power supply functions. The device operates within a temperature range of -40°C to 125°C (TA). Supply current is specified at 1mA. The component utilizes a 36-WLP package with dimensions of 3.23x2.96 mm. Mounting type is surface mount. ECCN classification is EAR99.

Power Management - Specialized Feature Summary

• Highly integrated battery charging and power supply solution
• Ultra-low power architecture for extended battery life
• Compact footprint suitable for space-critical designs

Power Management - Specialized Applications

• Battery management systems
• Low-power portable electronics
• Size-constrained IoT devices

Power Management - Specialized Procurement Notes

Verify the specific suffix 'AANX+T' against official Analog Devices documentation to confirm package type and tape-and-reel configuration. Ensure compatibility with existing PCB layout constraints regarding the 36-WLP form factor. Cross-reference thermal requirements against the -40°C to 125°C operating range. Confirm that the single-input topology aligns with system power source availability before procurement.

Power Management - Specialized Selection Notes

Select this component when minimizing board area is critical due to its 36-WLP packaging. Consider the ultra-low supply current for applications requiring minimal quiescent drain. Evaluate the integration of charging and power supply functions to reduce external component count. Verify that the single-input architecture meets the system's power input requirements without needing complex multi-source switching logic.

Power Management - Specialized Part Context

This part belongs to the MAX77658 family of specialized power management ICs. It is manufactured by Analog Devices Inc./Maxim Integrated. The series focuses on providing highly integrated solutions for low-power applications where efficiency and size are paramount. It serves as a complete power management block for battery-operated devices.

Power Management - Specialized Replacement Considerations

No public confirmed substitute part numbers are available in the provided data.
