MBR120VLSFX

$0.26

Description：MBR120VLSF/SOD123FL/SOD2
Series：-
Mfr：Nexperia USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:b8e437068b92 Category: Single Diodes Brand: Nexperia USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

MBR120VLSFX is listed in the Single Diodes range at ChipApex. The manufacturer field lists Nexperia USA Inc.. Its product description is MBR120VLSF/SOD123FL/SOD2. Review the specifications below when checking this part for your BOM.

Single Diodes specifications for MBR120VLSFX

Description：MBR120VLSF/SOD123FL/SOD2
Series：-
Mfr：Nexperia USA Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Technology：-
Voltage - DC Reverse (Vr) (Max)：-
Current - Average Rectified (Io)：-
Voltage - Forward (Vf) (Max) @ If：-
Speed：-
Reverse Recovery Time (trr)：-
Current - Reverse Leakage @ Vr：-
Capacitance @ Vr, F：-
Mounting Type：Surface Mount
Package / Case：SOD-123FL
Supplier Device Package：SOD-123FL
Operating Temperature - Junction：-
Grade：-
Qualification：-

Single Diodes datasheet and documents for MBR120VLSFX

MBR120VLSFX

Single Diodes Overview

The Nexperia MBR120VLSFX is a planar Schottky barrier rectifier featuring an integrated guard ring for stress protection, housed in a SOD123FL surface-mounted plastic package. It supports an average forward current of 1 A and a reverse voltage of 20 V. The device utilizes clip-bond technology to deliver high power capability within a small footprint. Key electrical characteristics include a maximum forward voltage of 450 mV at 1 A and a maximum reverse leakage current of 50 µA at 20 V.

Single Diodes Feature Summary

Planar Schottky barrier design with integrated guard ring for enhanced stress protection
High power handling capability achieved through clip-bond technology
Low forward voltage characteristic for improved efficiency
Compact SOD123FL small and flat lead surface-mount package

Single Diodes Applications

Low voltage rectification
High efficiency DC-to-DC conversion
Switch Mode Power Supply (SMPS)
Reverse polarity protection
Low power consumption applications

Single Diodes Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm packaging details such as reel size or tape-and-reel specifications. Confirm that the component version matches the required production status and revision level before finalizing procurement orders.

Single Diodes Selection Notes

Select this component for circuits requiring low forward voltage drop and compact surface-mount integration. Ensure the application operates within the specified junction temperature limits and accounts for thermal resistance values when designing heat dissipation strategies on FR4 PCBs.

Single Diodes Part Context

This part belongs to the Nexperia MBR120VLSF series of low VF Schottky barrier rectifiers. The series is engineered for high-efficiency power management applications where space constraints and low conduction losses are critical design parameters.

Single Diodes Replacement Considerations

Consult the manufacturer's official substitution guide for verified equivalent parts. Do not assume compatibility based solely on similar voltage or current ratings without verifying pinout and thermal characteristics.
