MC08XS6421DEK
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：IC HIGH SIDE SWITCH 12V 32SOIC
- Series：-
- Mfr：NXP USA Inc.
- Package：Tube
- Switch Type：General Purpose
- Number of Outputs：6
- Ratio - Input:Output：2:03
- Output Configuration：High Side
- Output Type：N-Channel
- Interface：SPI
- Voltage - Load：7V ~ 18V
- Voltage - Supply (Vcc/Vdd)：4.5V ~ 5.5V
- Current - Output (Max)：5.5A, 11A
- Rds On (Typ)：8mOhm, 21mOhm
- Input Type：-
- Features：Internal PWM
- Fault Protection：Current Limiting (Fixed), Open Load Detect, Over Temperature
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：32-HSOP
- Package / Case：32-SSOP (0.295", 7.50mm Width) Exposed Pad
- Grade：-
- Qualification：-
Download product information
Overview
The MC08XS6421DEK is an evaluation kit manufactured by NXP Semiconductors, designed for the MC08XS6421 high-side switch IC. This development tool supports a 12V system and features dual channels with 8.0 mOhms resistance and dual channels with 21.0 mOhms resistance. The kit facilitates the assessment of power distribution capabilities within automotive-grade applications, ensuring compatibility with AEC-Q100 standards for reliable operation in demanding environments.
Feature Summary
- Provides a dedicated hardware platform for evaluating the functional performance of the MC08XS6421 high-side switch integrated circuit.
- Supports analysis of dual-channel configurations with distinct on-resistance values to validate power distribution efficiency.
- Designed to assist engineers in verifying device behavior under specified voltage conditions during the prototyping phase.
Applications
- Evaluation of high-side switch performance in automotive electronic control units
- Prototyping and validation of power distribution networks in vehicle systems
- Assessment of thermal and electrical characteristics for AEC-Q100 qualified components
Procurement Notes
Verify that the specific part number MC08XS6421DEK corresponds to the intended evaluation kit configuration. Confirm compatibility with the target MC08XS6421 IC variant. Ensure that the supplier provides documentation confirming the kit includes all necessary components for accurate device testing. Check for any regional availability restrictions or specific handling requirements associated with semiconductor development tools.
Selection Notes
Select this kit when direct hardware evaluation of the MC08XS6421 high-side switch is required. It is suitable for engineers needing to validate dual-channel switching behavior and resistance parameters before full-scale production. Consider this option if the design process demands physical verification of power distribution characteristics in a controlled environment rather than relying solely on simulation data.
Part Context
This evaluation kit belongs to the MC08XS6421 series of high-side switches developed by NXP Semiconductors. These devices are engineered for robust power management in automotive applications, offering precise control over multiple load channels. The series emphasizes reliability and compliance with stringent automotive quality standards, supporting complex power distribution architectures in modern vehicles.
Replacement Considerations
No public confirmed substitute part numbers are available for this specific evaluation kit model. Development kits are typically unique to their corresponding IC variants and do not have direct interchangeable equivalents. Engineers should consult official NXP documentation for alternative development platforms if the current kit is unavailable.
