MC100EL31DTR2G is listed in the Flip Flops range at ChipApex. The manufacturer field lists onsemi. Its product description is IC FF D-TYPE SNGL 1BIT 8TSSOP. Review the specifications below when checking this part for your BOM.
Flip Flops specifications for MC100EL31DTR2G
- Description：IC FF D-TYPE SNGL 1BIT 8TSSOP
- Series：100EL
- Mfr：onsemi
- Package：Bulk
- Function：Set(Preset) and Reset
- Type：D-Type
- Output Type：Complementary
- Number of Elements：1
- Number of Bits per Element：1
- Clock Frequency：2.8 GHz
- Max Propagation Delay @ V, Max CL：-
- Trigger Type：Positive Edge
- Current - Output High, Low：-
- Voltage - Supply：-4.2V ~ -5.7V
- Current - Quiescent (Iq)：32 mA
- Operating Temperature：-40°C ~ 85°C (TA)
- Mounting Type：Surface Mount
- Supplier Device Package：8-TSSOP
- Package / Case：8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Input Capacitance：-
- Grade：-
- Qualification：-
Flip Flops datasheet and documents for MC100EL31DTR2G
Flip Flops Overview
The MC100EL31DTR2G is a single D-type flip-flop from the MC100EL series, designed for high-speed ECL applications. It features differential inputs and outputs with set and reset capabilities. The device operates within a supply voltage range of 4.2 V to 5.7 V and supports clock frequencies up to 2.8 GHz. It exhibits a propagation delay of 0.59 ns and functions reliably across an operating temperature range of -40°C to +85°C. The component is housed in an 8-pin TSSOP surface-mount package.
Flip Flops Feature Summary
- High-speed differential data and clock input architecture
- Integrated asynchronous set and reset functionality
- Complementary differential output configuration
Flip Flops Applications
- High-speed serial communication systems
- Clock distribution networks
- Data acquisition and processing circuits
Flip Flops Procurement Notes
Verify the specific suffix 'TR2G' against the manufacturer's official datasheet to confirm tape-and-reel packaging and RoHS compliance status. Ensure the ordering part number matches the exact electrical specifications required for the target application design.
Flip Flops Selection Notes
Select this component when differential signaling is required for noise immunity in high-frequency environments. The inclusion of set and reset pins provides additional control flexibility compared to standard D-flip-flops. Verify that the system power supply aligns with the specified ECL voltage requirements.
Flip Flops Part Context
This device belongs to the MC100EL family of emitter-coupled logic components. It shares functional similarities with the MC10EL31 but utilizes a TSSOP-8 package instead of SOIC-8. The 'TR2G' designation indicates a specific reel quantity and environmental compliance variant within the broader product line.
Flip Flops Replacement Considerations
The MC100EL52DTR2G serves as a comparable alternative within the same series, offering similar differential characteristics. Verify pin compatibility and specific timing parameters before substitution.
