MC100EP131FAR2

Flip Flops Overview

The MC100EP131FAR2G is a quad D-type flip-flop from the onsemi 100EP series, designed for high-speed ECL applications. It operates with a supply voltage range of 3 V to 5.5 V and features single-ended inputs with differential outputs. The device provides both inverting and non-inverting logic polarities. Packaged in an LQFP-32 surface-mount format, it exhibits a propagation delay of 0.6 ns. The component supports industrial temperature ranges from -40°C to +85°C and includes moisture sensitivity classification.

Flip Flops Feature Summary

• Integrates four independent D-type flip-flops within a single package for compact circuit design.
• Supports dual voltage operation at 3.3V and 5V ECL standards for flexible power integration.
• Converts single-ended input signals into fully differential output waveforms.

Flip Flops Applications

• High-speed digital data storage and buffering systems
• ECL-based clock distribution networks
• Telecommunications signal processing equipment

Flip Flops Procurement Notes

Verify the complete part number suffix, specifically 'R2G', against official onsemi documentation to ensure correct packaging and RoHS compliance status. Confirm that the LQFP-32 package variant matches the specific reel quantity requirements for the manufacturing process. Cross-reference the moisture sensitivity level details provided in the datasheet to determine appropriate handling protocols during assembly.

Flip Flops Selection Notes

Select this component when designing circuits requiring multiple synchronized D-type latching elements with low propagation delay. Ensure the system architecture accommodates single-ended input drivers and differential load requirements. Verify that the operating environment remains within the specified -40°C to +85°C temperature range and that the power supply stability falls within the 3 V to 5.5 V operational window defined by the manufacturer.

Flip Flops Part Context

This device belongs to the MC100EP family of emitter-coupled logic components manufactured by onsemi. The series focuses on high-frequency performance and reliability for demanding electronic applications. The specific model integrates four logic gates, offering a density advantage over discrete solutions while maintaining the speed characteristics typical of the ECL technology platform used in advanced digital systems.

Flip Flops Replacement Considerations

Consult official cross-reference guides for compatible quad D-type ECL flip-flops. Verify pinout compatibility and electrical specifications before substituting with alternative manufacturers' parts. Ensure any replacement maintains the same LQFP-32 package dimensions and thermal characteristics.
