MC100EP131MNR4G

Flip Flops Overview

The MC100EP131MNR4G is a high-speed ECL flip-flop manufactured by onsemi. It features four D-type flip-flops with both inverting and non-inverting outputs, designed for differential clock operation. The device operates within a supply voltage range of 3V to 5.5V and supports a maximum frequency exceeding 2GHz. It utilizes a 32-pin QFN package suitable for surface-mount applications.

Flip Flops Feature Summary

• Supports differential clock inputs for enhanced noise immunity
• Provides both inverting and non-inverting output configurations
• Includes input clamping circuitry to maintain stable states during open inputs

Flip Flops Applications

• High-speed data sampling circuits
• Differential clock distribution networks
• Parallel-to-serial conversion modules

Flip Flops Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm the specific suffix matches the required package variant. Check current availability status as this component may be subject to lifecycle changes or discontinuation notices from the manufacturer.

Flip Flops Selection Notes

Select this component when designing systems requiring precise timing with differential signaling. Ensure the power supply architecture supports the specified voltage range. Consider thermal management requirements associated with the QFN package form factor for reliable long-term operation.

Flip Flops Part Context

This part belongs to the MC100EP series of emitter-coupled logic devices. It serves as a fundamental building block for sequential logic in high-frequency digital systems. The series is characterized by low propagation delay and robust performance under varying load conditions.

Flip Flops Replacement Considerations

MC100EP131MNG
