Product Detailed Parameters
- Description：IC MOTOR DRIVER 6V-58V 56QFN
- Series：-
- Mfr：NXP USA Inc.
- Package：Tape & Reel (TR)
- Motor Type - Stepper：-
- Motor Type - AC, DC：-
- Function：Controller - Commutation, Direction Management
- Output Configuration：Half Bridge (3)
- Interface：SPI
- Technology：Power MOSFET
- Step Resolution：-
- Applications：-
- Current - Output：-
- Voltage - Supply：6V ~ 58V
- Voltage - Load：6V ~ 58V
- Operating Temperature：-40°C ~ 125°C (TA)
- Mounting Type：Surface Mount
- Package / Case：56-VFQFN Exposed Pad
- Supplier Device Package：56-QFN (8x8)
- Grade：Automotive
- Qualification：-
Download product information
Overview
The MC33GD3000EPR2 is a three-phase brushless DC motor controller manufactured by NXP USA Inc. It operates within a supply voltage range of 6V to 58V and supports load voltages from 6V to 58V. The device utilizes Power MOSFET technology and features an SPI interface for communication. It is housed in a 56-pin QFN (8x8 mm) package with an exposed pad, designated as the EPR2 suffix indicating tape and reel packaging. The component is rated for an operating temperature range of -40°C to 125°C TA.
Feature Summary
- Integrated commutation and direction management capabilities
- Supports three-phase brushless DC motor control applications
- Utilizes Power MOSFET technology for power driving
Applications
- Automotive systems
- Three-phase BLDC motor control
- Commutation and direction management tasks
Procurement Notes
Verify the specific ordering suffix EPR2 corresponds to the required tape and reel quantity of 2,000 units. Confirm that the 56-QFN package dimensions match the target PCB footprint. Ensure the 6V-58V operating range aligns with the system power supply specifications. Check for any additional thermal requirements associated with the exposed pad design in the final assembly process.
Selection Notes
Select this component when a dedicated solution for three-phase BLDC motors is required within the automotive sector. The integrated SPI interface allows for precise configuration and monitoring. The wide voltage range accommodates various automotive battery architectures. Consider the thermal performance of the QFN package relative to the expected current loads and ambient temperatures.
Part Context
This part belongs to the MC33GD series of motor drivers from NXP. It is designed specifically for robust automotive applications requiring reliable commutation. The integration of driver and controller functions reduces external component count. The 56-pin QFN package offers a compact form factor suitable for space-constrained electronic control units.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing firmware if replacing similar NXP devices. Ensure pin-to-pin compatibility and electrical characteristics match the original design requirements before substitution.
