MC58113

$63.46

Description：MAGELLAN MULTICTRL IC 1AXIS v1.2
Series：Magellan®
Mfr：Performance Motion Devices, Inc.
Package：Tray

SKU:11f676202da1 Category: Motor Drivers, Controllers Brand: Performance Motion Devices, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MAGELLAN MULTICTRL IC 1AXIS v1.2
Series：Magellan®
Mfr：Performance Motion Devices, Inc.
Package：Tray
Motor Type - Stepper：Bipolar
Motor Type - AC, DC：Brushless DC (BLDC), Brushed DC, PMSM, Servo, Stepper
Function：Controller - Commutation, Direction Management
Output Configuration：High Side, Low Side
Interface：CAN, RS-232, RS-485, SPI
Technology：CMOS
Step Resolution：1 ~ 1/256
Applications：Automation Control, General Purpose, Industrial, Medical, Servo
Current - Output：4mA
Voltage - Supply：2.97V ~ 3.63V
Voltage - Load：-
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：100-LQFP
Supplier Device Package：100-TQFP (14x14)
Grade：-
Qualification：-

Download product information

MC58113

Overview

The MC58113 is a single-axis motion controller from the Magellan family by Performance Motion Devices. It supports brushed DC, brushless DC, and stepper motors within a TQFP-100 package. The device operates on a supply voltage ranging from 3 V to 3.6 V with a maximum operating current of 170 mA. It functions across an industrial temperature range of -40°C to +85°C and includes humidity sensitivity classification.

Feature Summary

Integrates multi-motor control capabilities for single-axis applications
Supports diverse motor types including brushed DC, brushless DC, and step motors
Provides standard communication interfaces such as CAN, RS-232/485, and SPI

Applications

Brushed DC motor control systems
Brushless DC motor drive implementations
Stepper motor positioning applications

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and moisture sensitivity level prior to assembly. Ensure compatibility with the DK58113 development kit for initial validation. Check specific ordering suffixes against official datasheets to confirm functional variants.

Selection Notes

Select this component for single-axis motion control requiring support for multiple motor topologies. Consider the TQFP-100 package constraints and 3V to 3.6V logic requirements. Evaluate thermal performance within the specified -40°C to +85°C operational window. Utilize the Magellan ecosystem tools for configuration and debugging during design phases.

Part Context

Part of the Magellan series designed for integrated motion control solutions. Manufactured by Performance Motion Devices, Inc., it falls under PMIC and motor driver categories. The chip serves as a core controller for embedded motion systems, often paired with external power stages.
